Acer Aspire C24 1700 Upgrade M2 SSD and RAM

Title: Upgrading RAM and M.2 Storage on Acer Aspire C24-1700-UA91: A Step-by-Step Guide

Author: Simon

Introduction: Hello everyone, Simon here. Today, I’m excited to walk you through upgrading the RAM and M.2 storage on the Acer Aspire C24-1700-UA91. Whether you’re expanding your RAM or swapping out your storage for something larger, this guide is tailored to help you make those upgrades smoothly and efficiently.

Identifying Your Acer Aspire Model: First, ensure you’re working with the correct model. Flip your computer and look for the model number on the back. For this guide, we’re focusing on the Acer Aspire C24-1700-UA91.

Tools Required:

• Metal prying tool
• Phillips screwdriver (PH2 for the stand, PH1 for the M.2 drive)
• Replacement RAM (DDR4, PC4)
• New M.2 drive (optional)
• USB adapter for cloning (optional)
• Bootable USB installer for Windows (if doing a fresh install)

Process:

1. Removing the Stand and Cover:
   • Use the Phillips screwdriver to remove the four screws from the stand (note the different screw sizes).
   • Lift the stand straight up to remove it.
   • Use a metal prying tool to gently open the cover by starting at the corners and working around the edge.
2. Accessing the Internal Components:
   • Remove the metal plate covering the internal components by unscrewing it.
   • Locate the RAM slots and the M.2 drive.
3. Upgrading RAM:
   • Push the clips holding the RAM to release it. Remove existing RAM if necessary.
   • Align new RAM with the slot and press down until the clips lock it in place.
4. Replacing/Upgrading the M.2 Drive:
   • Unscrew and remove the existing M.2 drive.
   • If upgrading, place the new M.2 drive into the slot and screw it in place. Transfer the thermal pad from the old drive to the new one.
   • For data transfer, either clone the old drive to the new one using a USB adapter or perform a fresh Windows install.

Conclusion: Upgrading your Acer Aspire’s RAM and storage can significantly enhance its performance. Remember, adding RAM is straightforward, but upgrading the M.2 drive requires either cloning your existing drive or installing a new operating system.

Tips and Warnings:

• Be gentle when prying open the cover to avoid damaging internal components.
• Keep track of screw sizes and locations.
• Be cautious with the M.2 drive’s thermal pad.
• If cloning the drive, ensure you have the necessary tools and follow the steps carefully.
• A fresh OS install requires a bootable USB installer and a new Windows license.

Final Thoughts: I hope this guide makes your upgrade process easier and more understandable. If you have questions or need further guidance, feel free to leave a comment below.
