Dell G5 Gaming Computer Hardware Overview

Introduction

This guide provides an overview of the hardware components in the Dell G5 gaming computer, including instructions for upgrading or replacing certain parts.

Tools Required

• Phillips screwdriver
• Metal prying tool (optional)

External Overview

• Front: USB-C port, USB 3.0 ports, headphone and microphone jacks, power button.
• Back: 4 USB 3.1 ports, Ethernet port, exhaust fan, graphics card ports (DVI, HDMI, DisplayPort), power supply unit.

Internal Components Overview

1. Side Panel Removal:
   • Remove two screws with a Phillips screwdriver.
   • Slide the panel towards yourself and remove it.
2. Storage Options:
   • 2.5-inch Drive Slots: Two slots available with SATA power connectors. SATA cables are required for connection to the motherboard.
   • 3.5-inch Hard Drive Slot: Located towards the bottom. It uses a SATA connector and is easy to slide in and out after removing one screw.
3. RAM:
   • Located centrally on the motherboard. You can upgrade to a maximum of 64GB (e.g., 2x32GB).
4. M.2 SSD Slot:
   • Comes with a 512GB NVMe SSD. The slot supports full-length M.2 drives, allowing for upgrades.
5. CPU Fan and Heatsink:
   • Four screws secure the CPU fan and heatsink. Remove these to access the CPU.
6. Graphics Card:
   • Equipped with a 6-pin connector. The system can support an 8-pin connector for higher-end graphics cards.
7. Wi-Fi Card:
   • Located near the graphics card with antenna cables attached.
8. Power Supply Unit (PSU):
   • A proprietary Dell PSU, smaller than standard ones. To remove, unfasten screws and slide it out.
9. Motherboard Connections:
   • Includes various connectors for power, fans, and USB ports.

LED Lighting System

• Located on the front panel with a dedicated control board.

Front Panel Removal

• Use the knob to lift and push to the right to access LED lighting connectors.

Conclusion

This Dell G5 gaming computer offers various upgrade options, particularly in storage and memory. The compact design requires careful handling, especially when working with proprietary components like the PSU.

Additional Tips

• Ensure the computer is unplugged and grounded before attempting any upgrades.
• Keep track of all screws and components during disassembly.
• For major upgrades or if unsure, consult with a professional or refer to Dell’s official guides.
