Dell G5 Gaming Desktop Teardown Guide

Introduction

In this guide, we’re taking a closer look at the Dell G5 gaming desktop, a robust system designed for gamers. We’ll be disassembling the desktop to explore its internal components and potential for upgrades.

Getting Started

Front Panel Overview:

• Power button at the top right corner.
• Microphone and headphone jacks, three USB 3.0 ports, and a USB-C port located below the power button.
• Dell logo at the bottom right, with an indicator for the Intel i5 10th generation processor (varies with configurations).

Side Panel Removal

The Dell G5 has a single removable side panel on the right, held in place by two screws. Once these are loosened, slide the panel to the left and lift it to access the internals.

Internal Components

Once inside, you’re greeted with several key components:

• 2.5 Inch Drive Bay: Located at the top left corner, with power cables pre-installed. It supports SSD or HDD and requires a SATA cable for connection.
• RAM Slots: Four slots available, with one occupied by an 8GB DDR4 RAM. Supports up to 32GB of RAM.
• M.2 SSD Drive: Comes with a 512GB M.2 SSD, upgradeable to a longer size by shifting the securing screw to an alternate slot.
• Hard Drive: 1TB secondary drive, easily removable and upgradable.

Graphics Card and Power Supply

• Graphics Card: The desktop comes with an Nvidia GTX 1660 Ti, housed in a slot with a 6-pin power connector. The maximum length for an upgrade is about 10 inches due to space constraints.
• Power Supply: Proprietary design by Dell, not upgradable due to its unique size and fitting. The power supply is equipped with both 6-pin and 8-pin connectors for different graphics card needs.

Cooling and Fans

While the G5 has a small exhaust fan at the back, there’s room for installing a larger one. The front panel doesn’t come with a fan, but there’s potential for a custom installation.

Conclusion

The Dell G5 gaming desktop offers a solid foundation for gaming with room for some upgrades, particularly in storage and RAM. However, its proprietary power supply and compact design limit the scope of some upgrades, like the graphics card and additional cooling.

Remember to handle components with care during disassembly and reassembly. If you have any questions or need further clarification, feel free to comment below. Don’t forget to like and subscribe for more tech teardowns and guides!
