Dell Inspiron 5515 M 2 SSD Replacement Storage Upgrade

Title: How to Upgrade M.2 SSD on Dell Inspiron 5515

Author: Simon

Introduction: Hello, Simon here. In this tutorial, I’m going to show you how to upgrade the M.2 SSD drive in a Dell Inspiron 5515 to a larger capacity, specifically to a 1TB drive. I’ll guide you through each step of the process, ensuring you can successfully upgrade your laptop’s storage.

Steps for M.2 SSD Upgrade:

1. Identifying Your Laptop Model:
   • Ensure you have a Dell Inspiron 5515, as the procedure might vary slightly with different models.
2. Removing the Back Cover:
   • Start by using a Phillips screwdriver to remove all the screws from the laptop’s back cover.
   • Note: The screws on the top left and top right corners do not come off completely. Just loosen them enough to open the back cover.
   • Gently pry open the back cover to access the internal components.
3. Locating the M.2 SSD:
   • The M.2 SSD is typically located beneath a protective cover. You may also find an additional slot for expanding your storage with another M.2 SSD.
4. Removing the Existing M.2 SSD:
   • Carefully remove the cover protecting the SSD.
   • Unscrew and gently slide out the existing M.2 SSD from its slot.
5. Installing the New M.2 SSD:
   • Take your new 1TB M.2 SSD and insert it into the slot at a 45-degree angle.
   • Secure it with the screw to ensure it is firmly in place.
6. Reassembling the Laptop:
   • Replace the protective cover and ensure it’s properly seated.
   • Close the back cover of the laptop and screw it back into place.
7. Post-Installation Steps:
   • After installation, your laptop will not boot to Windows as the new SSD is empty. You’ll need a Windows installation media to install a fresh operating system.
   • You can create a bootable Windows USB drive or use a pre-made one. Links to instructions or purchase options can be found in the video description.
   • Alternatively, you can clone your old drive to the new one using cloning software. This process will transfer all your data, including the operating system, to your new SSD.

Conclusion: Upgrading your M.2 SSD on a Dell Inspiron 5515 is a straightforward process that can significantly increase your storage capacity. With careful attention to detail, you can easily perform this upgrade at home.

Additional Tips:

• Remember to handle your laptop’s internal components with care.
• If you choose to clone your old SSD to the new one, ensure you have the necessary cloning software and equipment.

Closing Remarks: I hope this tutorial was helpful. If you succeeded in upgrading your SSD, please give this video a like and consider subscribing for more tech guides. If you have any questions, feel free to ask in the comments below. Thanks for watching, and good luck with your upgrade!
