Dell Vostro 3681 (D15S) NVMe M.2 SSD Upgrade Guide

Introduction

• Objective: Upgrade the NVMe M.2 SSD on a Dell Vostro 3681 (D15S) to increase storage capacity.
• Tools Needed: Phillips screwdriver, new NVMe M.2 SSD, potentially a Windows installation USB, and optional USB adapter for data transfer.

Steps for NVMe M.2 SSD Upgrade

1. Preparation:
   • Power off the Dell Vostro 3681.
   • Ensure you have the correct NVMe M.2 SSD (not a SATA M.2 SSD).
   • Have a Phillips screwdriver handy.
2. Opening the Case:
   • Remove the two screws on the back side panel using the Phillips screwdriver.
   • Slide the panel towards the left and remove it to expose the internals.
3. Removing Front Panel (Optional):
   • Locate three clippers (top, middle, bottom) and slide them out to remove the front panel.
4. Removing the Bracket:
   • Unscrew and remove the bracket that holds additional drives (2.5 inch or 3.5 inch).
5. Accessing the M.2 SSD Slot:
   • Identify the existing M.2 SSD slot. The NVMe SSD will have one notch (opposed to SATA M.2 with two notches).
   • Remove the screw securing the M.2 SSD.
   • Gently lift the SSD at a 45-degree angle and slide it out. Note the presence of a thermal pad which might make it slightly sticky.
6. Installing the New NVMe M.2 SSD:
   • Move the screw to the new position if using a longer SSD.
   • Insert the new NVMe M.2 SSD at a 45-degree angle and then press it down.
   • Secure it with the screw.
7. Reassembling:
   • Reattach the bracket for additional drives if necessary.
   • Slide the front panel back on if it was removed.
   • Put back the side panel and secure it with the screws.
8. Windows Installation:
   • If starting fresh, use a Windows installation USB to install Windows on the new SSD.
   • If cloning from the old drive, use cloning software and a USB adapter.

Additional Tips

• Data Cloning: If you want to clone your existing drive, use Acronis or similar software with a USB adapter. (Check the related video for detailed steps).
• Windows Installation: If you don’t have a Windows USB installer, you can create one using Microsoft’s tool from their official website.
• RAM Upgrade: Consider upgrading RAM alongside the SSD for improved performance (refer to a separate guide for this).

Conclusion

Upgrading the NVMe M.2 SSD on your Dell Vostro 3681 is a straightforward process that can significantly enhance your storage capacity. Ensure you handle the components with care and follow the steps accurately. If you encounter any issues or feel uncertain, it’s advisable to consult a professional. Good luck with your upgrade!
