Dell Vostro 7620 P117F Teardown Disassemble Upgrade

Title: Dell Vostro 7620 Disassembly and Upgrade Guide

Author: Simon

Introduction: Hi everyone, Simon here! In this tutorial, I’ll be disassembling the Dell Vostro 7620 (Model: P117F003) and guiding you through upgrades for RAM, hard drive, and battery replacement.

Tools Required:

• Phillips Screwdriver (small size)
• Plastic Pry Tool

Disassembly Steps:

1. Identifying the Model: Ensure you have the Dell Vostro 7620, Model P117F003.
2. Removing the Back Cover:
   • Use the Phillips screwdriver to remove all screws from the back cover.
   • Pry open the back cover using a plastic pry tool.
3. Exploring the Internal Components:
   • Battery: Located at the bottom.
   • CPU and GPU fans: With associated heatsinks.
   • M.2 NVMe SSD slot.
   • 8GB DDR5 RAM.
   • Wi-Fi card.
4. Battery Replacement:
   • Remove the plastic covering the battery connector.
   • Slide down the battery connector.
   • Unscrew and remove the battery. (Model for replacement: 8F CTC)
5. M.2 SSD Upgrade:
   • Remove the screw and slide out the existing M.2 SSD.
   • If upgrading to a full-sized SSD, remove the extension bracket.
   • Install the new SSD and secure it with the screw.
6. RAM Upgrade:
   • Push the clips to release the RAM stick.
   • Slide out the existing RAM and replace it with new DDR5 RAM.
   • Ensure proper alignment and press down to secure.
7. Reassembly Tips:
   • Reconnect the battery and other disconnected components.
   • Carefully align and press down the back cover.
   • Screw the back cover into place.

Conclusion: This guide should help you comfortably navigate through upgrading your Dell Vostro 7620. Remember, handling internal components requires care and proper tools.

Additional Tips:

• Keep track of screws and their respective places.
• Handle components gently to avoid any damage.
• Make sure your work area is clean and organized.
