Gigabyte AERO 15 Laptop Fan Replacement Guide

Introduction

• Model: Gigabyte AERO 15 (or AERO 15X)
• Objective: CPU Fan Replacement

Tools Required

• Torx T6 Screwdriver
• Phillips Screwdriver
• Plastic Prying Tool

Disassembly Steps

1. Remove Back Plate:
   • Use the Torx T6 screwdriver to remove the top screws.
   • The Y-shaped screws at the top are longer than the others.
   • Use a plastic prying tool to gently lift and remove the back plate.
2. Battery Removal:
   • The battery is attached with double-sided tape.
   • Carefully peel off the tape and disconnect the battery connector.
   • Model for replacement battery: GAG-J40 (if needed).
3. RAM Upgrade/Replacement:
   • The laptop has DDR4 RAM (16 GB installed).
   • You can add another 16 GB for a total of 32 GB.
   • To install or remove the RAM, slide it in at an angle and click it into place or use thumbs to release clips.
4. CPU Fan Removal:
   • Disconnect the CPU fan power connectors.
   • Unscrew and remove the entire heatsink to access the fans.
   • If thermal paste is dry, clean with alcohol wipes and apply new thermal paste.
   • Unscrew the faulty fan (four screws) and replace it.
   • Fan model for reference: BS005HS-U2M.
5. SSD Replacement/Upgrade:
   • The laptop includes an NVMe SSD drive.
   • For upgrades or replacement, locate the SSD slot and replace the drive.
   • Installing a new SSD will require a Windows installation.
6. Other Components:
   • Speaker: Easily removable, no screws.
   • Wi-Fi Card: Replaceable, located near the battery.
   • Motherboard: Involves disconnecting several cables and removing screws.
7. Keyboard Replacement:
   • The keyboard is integrated into the palm rest and is not separately replaceable.
   • A damaged keyboard requires replacing the entire bottom assembly.

Reassembly

• Reverse the Disassembly: Follow the disassembly steps in reverse order, ensuring all components are securely reconnected and screws are tightened.

Special Notes

• Handle Components Carefully: Components like the motherboard are delicate and should be handled with care.
• Thermal Paste Application: Apply thermal paste evenly and sparingly for effective heat conduction.

Conclusion

• This guide covers disassembling a Gigabyte AERO 15 laptop for a CPU fan replacement and explains how to access and replace other key components.

Assistance

• If you have any questions or encounter issues during the process, please comment below for assistance.
