HP Spectre X360 Tear Down Full Disassemble

HP Spectre x360 15-ch011dx Teardown Guide

Introduction:

• Objective: Disassemble HP Spectre x360 (Model: 15-ch011dx) to address a swollen battery issue.
• Scope: Guide covers steps to access and replace key components including the battery, motherboard, heatsink, RAM, and more.

Tools Required:

• Phillips screwdriver
• T5 Torx screwdriver
• Plastic prying tool

Disassembly Steps:

1. Removing Rubber Stoppers and Screws:

• Remove rubber stoppers at the back to expose hidden screws.
• Use Phillips and T5 Torx screwdrivers for different screws.

2. Removing the Back Plate:

• Gently pry open and remove the back plate.

3. Battery Removal:

• Notice the swollen battery pushing against the back plate.
• Remove screws securing the battery and carefully lift it out.

4. Disconnecting Cables:

• Disconnect various cables including those for keyboard lighting, touchpad, SD card reader, and speakers.
• Carefully flip open cable clippers where needed.

5. Removing the CPU Fan:

• Unscrew the fan and disconnect its cable.
• Good opportunity to clean the fan if dusty.

6. Accessing RAM and SSD:

• Remove cover protecting the RAM and SSD.
• Two RAM slots with DDR4 RAM available for upgrade or replacement.
• M.2 SSD drive can also be replaced or upgraded.

7. Wi-Fi Card Removal:

• Unscrew and remove the Wi-Fi card if needed.

8. LCD Screen Disconnection:

• Remove screws from hinges.
• Open LCD to 180 degrees to access and disconnect cables.

9. Motherboard Removal:

• Ensure all cables are disconnected.
• Unscrew and gently lift out the motherboard.
• Note: Good time to apply new thermal paste on CPU and GPU if needed.

10. Remaining Components:

• DC jack and power button can be replaced individually.
• Speakers can be accessed and replaced.
• Touchpad and keyboard are part of the base assembly and not individually replaceable.

Conclusion:

• Reassembly: Reverse the disassembly steps carefully.
• Handling: Be gentle with all components, especially when disconnecting cables and removing the motherboard.
• Disposal of Battery: Swollen batteries are hazardous. Dispose of them properly at a local battery disposal facility.

Tips:

• Take photos at each step for easier reassembly.
• Keep track of screws and their respective locations.
• Handle the LCD and other delicate components with extra care.
