iPhone 12 Pro Screen Replacement Start to Finish

Title: How to Replace a Cracked Front Screen on an iPhone 12 Pro

Author: Simon

Introduction: Hello everyone, it’s Simon here. In this tutorial, I’m excited to guide you through the process of replacing a cracked front screen on an iPhone 12 Pro. This step-by-step guide is designed to help you confidently perform the replacement at home.

Tools Needed:

• 0.8 Pentalobe screwdriver
• Metal prying tool
• Tri-point (Y) screwdriver
• Phillips screwdriver (PH000 size)

Steps for Screen Replacement:

1. Removing Bottom Screws:
   • Start by removing the two screws at the bottom of your iPhone with the 0.8 Pentalobe screwdriver. If a screw is missing, proceed with the existing one.
2. Detaching the Screen:
   • Use a metal prying tool to gently separate the screen from the phone’s frame. Apply minimal depth to avoid internal damage.
   • Optionally, use a heat gun to soften the adhesive for easier removal.
3. Disconnecting the Battery and Screen:
   • Switch to the tri-point screwdriver to remove the screws securing the battery and screen connectors.
   • Carefully disconnect the battery followed by the screen connectors.
4. Transferring Proximity Sensor and Speaker:
   • Remove the screws holding the proximity sensor and front speaker using the Phillips screwdriver.
   • Gently detach the Flex cable and transfer the proximity sensor and speaker to the new screen.
5. Reassembly:
   • Attach the new screen by reconnecting the Flex cables. Ensure they are properly aligned before pressing to connect.
   • Reattach the battery connector and secure the brackets back in place with their respective screws.
6. Final Steps:
   • Align the top of the screen first when placing it back onto the phone. Ensure it fits into place before pressing down the edges.
   • Finish by reinstalling the two screws at the bottom of the phone.

Conclusion: Replacing the front screen of your iPhone 12 Pro can be a straightforward process with the right tools and patience. Take your time with each step, especially when handling the Flex cables and the reattachment of the new screen.

Tips and Warnings:

• Be gentle when prying open the screen to avoid damaging the internals.
• Keep track of screws and their respective places, as they vary in size.
• Ensure the connectors are properly aligned before pressing to avoid damaging the pins.
• Test the functionality of the phone before sealing the screen completely.

Final Thoughts: With this guide, I hope you feel more confident in replacing your iPhone’s cracked screen. If you find this video helpful, please hit the like button and consider subscribing for more tech repair tutorials.

Call to Action: If you have any questions or need further assistance, don’t hesitate to drop a comment below. Thanks for watching, and I’ll see you in the next tutorial!
