iPhone 6 Screen Replacement Tutorial

Preparation

• Phone Model: iPhone 6
• Goal: Replace a damaged screen.

Tools Needed

• Phillips screwdriver
• Prying tool
• Replacement screen

Steps

1. Removing Bottom Screws:
   • Remove two screws at the bottom near the charging port.
2. Opening the Case:
   • Use a prying tool to gently lift the screen, breaking the adhesive seal.
3. Disassembling Internal Components:
   • Remove the five screws holding the bracket over the flex cable and lift off the bracket.
   • Disconnect the battery to ensure safety during screen removal.
   • Detach the four flex cables connected to the screen.
4. Transferring Components to New Screen:
   • Remove the backplate from the original screen.
   • Transfer the home button, front camera, and earpiece speaker to the new screen.
   • Carefully align and reattach these components using the screws removed earlier.
5. Reassembling:
   • Reattach the flex cables in the correct order: leftmost cable first, then the middle, followed by the top cable (home button) and the camera.
   • Replace the bracket over the flex cables and secure with screws.
   • Reconnect the battery and secure its bracket.
   • Carefully align the top of the screen (with the earpiece) into the phone case and gently snap the screen into place.
   • Secure the bottom screws.

Conclusion

• Difficulty: Moderate. Requires careful handling of small components and delicate cables.
• Time Required: Approximately 30 to 60 minutes, depending on skill and experience.
• Note: Ensure correct alignment of components and gentle handling to prevent damage.
