iPhone X Screen Replacement Guide

Hi, Simon here. In this video, I’ll be guiding you through the process of replacing the screen on an iPhone X. If you’re dealing with a cracked screen, be sure to hit the like button and subscribe for more helpful guides!

Tools and Parts Needed

• Pentalobe 0.8 screwdriver
• Metal prying tool
• Replacement screen (links for purchase in the description)

Steps for Screen Replacement

1. Preparing the iPhone

• Ensure the iPhone is powered off.
• Remove the two screws at the bottom of the iPhone using the Pentalobe screwdriver.

2. Removing the Bezel and Cutting the Adhesive

• Use the metal prying tool to gently cut through the adhesive around the screen. This adhesive is part of the water-resistant seal.

3. Disconnecting the Battery and Screen

• Carefully open the screen to the right side.
• Notice the water damage indicators (red color) if present.
• Use a Y000 (Tri-point) screwdriver to remove the bracket over the battery and screen connectors.
• Disconnect the battery (third connector from the right).
• Disconnect the LCD and digitizer cables (second and first from the right).

4. Removing the Proximity Sensor

• Remove screws holding the proximity sensor and front camera in place.
• Carefully transfer the entire assembly to the new screen.

5. Installing the New Screen

• Align the new screen and reconnect the digitizer, LCD, and battery cables.
• Replace the bracket and screws over the connectors.
• Slide the top of the screen into the frame first, then press the sides and bottom back into place.

6. Final Steps

• Replace the two Pentalobe screws at the bottom.
• Power on the iPhone to test the new screen.

That’s it for this iPhone X screen replacement tutorial. If you have any questions, please leave them in the comments below. Remember to like and subscribe for more tutorials like this. Take care, and see you in the next video!
