LG Gram 16T90P Teardown Disassemble Upgrade

Title: LG Gram Laptop Teardown and Upgrade Tutorial

Author: Simon

Introduction: Hi everyone, Simon here! Today, we’re going to take apart an LG Gram laptop (model 16T90P) to explore potential upgrades like RAM, SSD, battery replacement, CPU fan, and thermal paste application.

Preparation: Before we begin, ensure you have a metal prying tool and a Phillips screwdriver handy.

Procedure:

1. Remove Rubber Stoppers: Start by removing the rubber stoppers at the laptop’s bottom using a metal prying tool. They’re held in place with double-sided tape and conceal the screws.
2. Unscrew and Open the Back Cover: Remove all the screws using a Phillips screwdriver. The screws on the top are darker in color, while the others are silver. Carefully pry open the back cover using a plastic tool.
3. Inside the Laptop:
   • SSD: The nvme SSD drive is easily accessible for upgrade.
   • Battery: The LG battery can be replaced by disconnecting and unscrewing it.
   • Wi-Fi Card and Bluetooth: Located next to the battery.
   • CPU Fan and Heatsink: For cooling the processor.
   • RAM: Unfortunately, the RAM is soldered to the motherboard and not upgradable.
4. Upgrading the SSD:
   • Remove the existing SSD by unscrewing and sliding it out.
   • If desired, you can install a larger capacity SSD.
   • Optionally, use an nvme USB adapter for cloning your old SSD to the new one.
5. Battery Replacement:
   • Disconnect the battery connector by sliding it towards you.
   • Remove the screws holding the battery and replace it if necessary.
6. CPU Fan and Heatsink:
   • Clean or replace the CPU fan if it’s dusty or malfunctioning.
   • If your laptop overheats, consider reapplying thermal paste. Clean off the old paste and apply a generous new layer on the CPU.
7. Other Components:
   • The keyboard is integrated into the palm rest and not individually replaceable.
   • The motherboard can be removed by disconnecting all cables and removing screws, but it’s a more complex process.

Conclusion: This LG Gram model offers limited upgradeability, primarily in storage and battery. The RAM and CPU are not upgradable. Always remember to handle components with care during any disassembly.
