MacBook Pro A1708 (2017) Screen Replacement Tutorial

Introduction

Welcome to this tutorial! Today, we’ll be replacing the screen of a MacBook Pro A1708, the 2017 model. This guide also applies to the 2016 model. Let’s dive in!

Tools and Parts Required

• Pentalobe screwdriver
• Plastic prying tool
• Torx 5 and Torx 8 screwdrivers
• Replacement screen for MacBook Pro A1708 (links provided in the description for eBay and Amazon purchases)

Step-by-Step Guide

1. Removing the Back Cover: Start by removing all screws using the pentalobe screwdriver. The four screws at the top (near the hinge) are longer than the bottom two. Use a prying tool to gently pop open the back plate and slide it towards you to remove.
2. Disconnecting the Battery: Lift the plastic cover inside to reveal the battery connector. Flip up the tiny clip and slide the flex cable to the left to disconnect. Slightly lift the metal plate that holds the battery connector to disconnect the battery.
3. Removing the Wi-Fi Antenna and LCD Board: Unscrew the brackets holding the Wi-Fi antenna and LCD board. Carefully disconnect the Wi-Fi cables by prying them upwards.
4. Transferring Components to the New Screen: If your new screen doesn’t come with certain components (like a bracket for the flex cable), you’ll need to transfer these from the old screen.
5. Removing the Hinges: Unscrew the hinges using the Torx 8 screwdriver. You’ll find three screws on each hinge.
6. Installing the New Screen: Open the hinges on the new screen slightly more than 90 degrees and align them with the body of the MacBook. First, slide one corner in, ensuring all cables are on top, not pinched underneath, and then do the same on the other side.
7. Securing the Hinges: Place one screw on each side to secure the hinges, then close the MacBook and finish screwing the hinges.
8. Reconnecting Components: Reconnect the Wi-Fi antenna and LCD board cables. Ensure all cables are correctly aligned and gently snap or slide them into place.
9. Final Steps: Before closing everything up, make sure everything is aligned correctly, and no cables are out of place. Replace the back cover by sliding it into place and then pressing down to secure the clips. Finally, screw the back cover back in place.

Testing

Turn on your MacBook Pro to ensure the screen is working correctly. If everything looks good, you’ve successfully replaced your MacBook screen!

Conclusion

Screen replacement might seem daunting, but with the right tools and patience, it’s doable. If you encounter any issues or have questions, feel free to drop a comment below. Don’t forget to like and subscribe for more tutorials. Take care, and good luck with your repair!
