MacBook A1398 Screen Replacement 2013 2014

Title: MacBook Pro Full Assembly LCD Screen Replacement Guide

Introduction:

• Simon introduces the video, focusing on how to replace the full assembly LCD screen of a 15-inch MacBook Pro, Model A1398.
• He has a used screen ready for replacement and mentions that new or used screens are available on Amazon or eBay.

Steps for Screen Replacement:

1. Initial Preparations:
   • Simon begins by removing the back cover of the MacBook Pro using a Pentalobe P5 screwdriver.
2. Accessing Internal Components:
   • Once the back cover is removed, Simon suggests cleaning the fan with a can of compressed air.
   • He removes two small rubber pieces to access the hinge screws.
3. Disconnecting Cables:
   • He disconnects the Bluetooth and Wi-Fi cables by lifting them straight up.
   • The webcam cable is slid to the left for removal.
   • For the LCD screen cable, he opens a safety clipper and slides the cable to the right.
4. Removing the Old Screen:
   • Simon uses a T4 screwdriver to remove a special screw from each hinge.
   • He then switches to a T8 screwdriver to remove three major screws from each hinge.
   • With the screws removed, he opens the screen to about 90 degrees and detaches it.
5. Installing the New Screen:
   • The new screen is positioned and aligned with the hinges.
   • Simon encounters a slight difficulty in closing the screen but manages to align and secure it with screws.
6. Reconnecting Cables:
   • He reconnects the webcam and Wi-Fi cables, ensuring they are properly aligned and secured.
   • The special screws are reattached to the hinges with the T4 screwdriver.
7. Final Steps:
   • The battery is reconnected, and the back cover is placed back onto the laptop.
   • Simon concludes by using the Pentalobe screwdriver to secure the back cover with screws.

Conclusion:

• Simon ends the video by inviting viewers to like and subscribe to his channel for more repair videos.
• He encourages viewers to check the video description for links to purchase tools and screens, and to comment with any questions.

Summary: The video provides a detailed guide on replacing the full assembly LCD screen of a 15-inch MacBook Pro (Model A1398). Simon demonstrates each step, from opening the laptop and removing the old screen to installing a new screen and reassembling the laptop. He offers tips and advises on the necessary tools, aiming to assist viewers in successfully completing the screen replacement process.
