Macbook Air A1466 Tear Down Full Disassemble

[vc_row][vc_column][vc_video link=”https://www.youtube.com/watch?v=GLgI3w9VaVo” title=”Macbook Air A1466 Tear Down Full Disassemble”][vc_raw_html]JTNDc2NyaXB0JTIwYXN5bmMlMjBzcmMlM0QlMjJodHRwcyUzQSUyRiUyRnBhZ2VhZDIuZ29vZ2xlc3luZGljYXRpb24uY29tJTJGcGFnZWFkJTJGanMlMkZhZHNieWdvb2dsZS5qcyUzRmNsaWVudCUzRGNhLXB1Yi04MDk0NDMzMDk5ODI1MDMwJTIyJTBBJTIwJTIwJTIwJTIwJTIwY3Jvc3NvcmlnaW4lM0QlMjJhbm9ueW1vdXMlMjIlM0UlM0MlMkZzY3JpcHQlM0UlMEElM0MlMjEtLSUyMFNxdWFyZSUyMEFkJTIwQmxvZyUyMC0tJTNFJTBBJTNDaW5zJTIwY2xhc3MlM0QlMjJhZHNieWdvb2dsZSUyMiUwQSUyMCUyMCUyMCUyMCUyMHN0eWxlJTNEJTIyZGlzcGxheSUzQWJsb2NrJTIyJTBBJTIwJTIwJTIwJTIwJTIwZGF0YS1hZC1jbGllbnQlM0QlMjJjYS1wdWItODA5NDQzMzA5OTgyNTAzMCUyMiUwQSUyMCUyMCUyMCUyMCUyMGRhdGEtYWQtc2xvdCUzRCUyMjg2MjIwOTkzNTklMjIlMEElMjAlMjAlMjAlMjAlMjBkYXRhLWFkLWZvcm1hdCUzRCUyMmF1dG8lMjIlMEElMjAlMjAlMjAlMjAlMjBkYXRhLWZ1bGwtd2lkdGgtcmVzcG9uc2l2ZSUzRCUyMnRydWUlMjIlM0UlM0MlMkZpbnMlM0UlMEElM0NzY3JpcHQlM0UlMEElMjAlMjAlMjAlMjAlMjAlMjhhZHNieWdvb2dsZSUyMCUzRCUyMHdpbmRvdy5hZHNieWdvb2dsZSUyMCU3QyU3QyUyMCU1QiU1RCUyOS5wdXNoJTI4JTdCJTdEJTI5JTNCJTBBJTNDJTJGc2NyaXB0JTNF[/vc_raw_html][/vc_column][/vc_row][vc_row][vc_column][vc_column_text]

MacBook Air A1466 (2013-2017) Complete Teardown Guide

Introduction:

  • Objective: Complete disassembly of MacBook Air A1466 (2013-2017 models).
  • Purpose: Understand how to replace various components like the screen, motherboard, battery, SSD, and CPU fan.

Tools Required:

  • T5 (Torx) screwdriver
  • Plastic prying tool

Steps:

1. Removing the Back Plate:

  • Screws: Use the T5 screwdriver to remove screws from the back plate.
  • Battery Screws: There are additional screws securing the battery which need to be removed.
  • Note: Keep track of all screws and their positions for reassembly.

2. Battery Removal:

  • Model Numbers: For battery replacement, look for model number 1496 or 020-8142-A.
  • Process: Remove the battery by disconnecting it and unscrewing.

3. SSD Drive Removal:

  • Upgrade Option: SSD drive can be upgraded. Simply remove the current SSD drive from its slot.

4. Disconnecting Various Components:

  • Keyboard Backlight Cable: Disconnect this first.
  • Touchpad, I/O Board, and Speaker Cables: Disconnect these carefully.
  • Wi-Fi Card: Remove with caution, as the cable is delicate.

5. Removing the Fan:

  • Screws: Remove screws holding the fan.
  • Fan Cable: Don’t forget to disconnect the fan cable.

6. I/O Board and USB Port:

  • Removal: This comes out as one piece and includes the USB and audio jack.

7. Motherboard Removal:

  • Wi-Fi Card Removal: This needs to be done before removing the motherboard.
  • Screws: Remove all screws securing the motherboard.
  • Careful Handling: Handle the motherboard gently to avoid any damage.

8. LCD Screen Removal:

  • Hinge Screws: Remove screws from both hinges.
  • Lifting Screen: Open the MacBook slightly to push the hinges and remove the screen.

9. Final Components:

  • Speakers: These are attached to the keyboard.
  • Touchpad: Can be replaced by removing its screws.

Conclusion:

  • Reassembly: Follow the steps in reverse order for reassembly.
  • Caution: Handle all components, especially the motherboard and Wi-Fi card, with care.
  • Compatibility Check: Always check for compatible parts using model numbers for replacements.

Tips:

  • Keep a careful note of where each screw comes from, as they may vary in size and length.
  • Be particularly careful with the LCD screen and the delicate cables during both disassembly and reassembly.
