MacBook Pro 13 2016 17 Top Case Assembly A1708 Keyboard Touchpad Battery Replacement

Title: MacBook Pro Battery Replacement Guide

Author: Simon

Introduction: Hello, Simon here. Today, I’m going to show you how to replace the battery on a MacBook Pro. This model, A1708, involves replacing the entire palm rest assembly, which includes the keyboard, trackpad, and battery. While some might prefer to replace just the battery, my experience suggests replacing the whole unit is more efficient, especially with damaged or swollen batteries.

Tools Needed:

• Pentalobe P5 screwdriver
• T4 and T8 screwdrivers
• Plastic prying tool
• Replacement palm rest assembly (including battery, keyboard, and trackpad)

Procedure:

1. Remove the Back Cover: Start by removing all screws from the back cover using the Pentalobe P5 screwdriver. Carefully lift and slide out the back cover.
2. Disconnect the Battery: Use the plastic prying tool to open the battery connector’s clip and disconnect it. Remove the screw holding the battery using the T4 screwdriver.
3. Dismantle the Internal Components:
   • Use the T4 screwdriver to start removing components, beginning with the screen.
   • Take photos as a reference for screw placements.
   • Remove the Wi-Fi antenna, hinges, LCD board, and other connectors.
   • Carefully transfer the motherboard to the new palm rest assembly.
4. Reassemble the Components:
   • Position the motherboard in the new assembly, ensuring all cables are properly placed.
   • Reconnect all the cables and components in reverse order, starting with the motherboard and working your way to smaller components.
   • Reattach the Wi-Fi antenna, LCD board, and screen.
5. Final Steps:
   • Reconnect the battery and close the clip.
   • Place the back cover, slide it into position, and screw it back in place.

Conclusion: Replacing the MacBook Pro battery requires patience and attention to detail. It’s crucial to handle internal components carefully and keep track of all screws and their positions.

Tips:

• Organize screws and small parts to avoid losing them.
• Handle cables and connectors gently to avoid damage.
• Charge the MacBook Pro with its charger immediately after the replacement.

Call to Action: If this guide was helpful, please give it a like and subscribe for more tutorials. Drop your questions or comments below – I read and respond to them!

Closing: Thanks for following this guide on MacBook Pro battery replacement. For any further assistance, don’t hesitate to reach out in the comments. See you in the next tutorial, and take care!

Note: Remember to plug in the charger to turn on the MacBook Pro after battery replacement, as the system might not recognize the new battery immediately.
