MacBook Pro 13″ Screen Replacement Guide

Hello, I’m Simon, and in this tutorial, I’ll guide you through replacing the screen on a MacBook Pro 13-inch, specifically the late 2016 or early 2017 model (A1706). Follow along as I take you step-by-step through this process.

Tools and Preparation

• Essential Tools: Torx screwdrivers, pentalobe screwdriver, metal and plastic prying tools.
• Screen Replacement: Ensure you have a compatible replacement screen.
• Model Verification: Check your MacBook’s model number on the back to confirm compatibility.

Initial Steps

1. Removing Screws: Use a pentalobe screwdriver to remove the bottom screws. Note the different screw sizes.
2. Opening the Case: Carefully pry open the case using the metal prying tool and release the clips holding the case.
3. Disconnecting the Battery: Remove the battery’s plastic cover, disconnect its connector, and unscrew it for safety during the screen replacement process.

Screen Replacement Process

1. Removing LCD Board: Use a T4 screwdriver to remove screws and free up the LCD board. Pay special attention to fragile connectors.
2. Transferring Brackets: Transfer the necessary brackets from the old screen to the new one.
3. Disconnecting Wi-Fi Antennas: Carefully disconnect the Wi-Fi antennas by sliding them out of their slots.
4. Removing Old Screen: Open the screen fully and gently slide out the old screen.
5. Installing New Screen: Position the new screen correctly, ensuring all cables are properly placed, and slide it into position.
6. Reconnecting Components: Carefully reconnect the LCD board, Wi-Fi antennas, and brackets.
7. Securing the Hinges: Use a T8 screwdriver to secure the screen’s hinges.
8. Battery Reconnection: Reattach and reconnect the battery.

Finalizing the Replacement

1. Testing the Screen: Before closing up the MacBook, it’s wise to test the new screen.
2. Closing the Case: Carefully align the case and snap the clips back into place.
3. Screw Reattachment: Secure the case with all the screws in their appropriate places.

Conclusion

Replacing a MacBook Pro screen can be a delicate process but is achievable with the right tools and patience. If this guide was helpful, please give a thumbs up, subscribe for more tutorials, and feel free to ask questions or share your experience in the comments. Until next time, thank you and goodbye!
