MSI GF65 Laptop – Screen Replacement

MSI GF65 Thin 9SEXR Gaming Laptop Screen Replacement Guide

Introduction

• Objective: Replace the cracked screen of an MSI GF65 Thin 9SEXR gaming laptop.
• Tools Required: Plastic and metal prying tools, potentially additional tools like a screwdriver.

Steps for Screen Replacement

1. Preparing the Laptop:

• Turn off the laptop and unplug any cables.
• Note: The bezel (screen frame) is likely attached with double-sided tape, not screws.

2. Removing the Bezel:

• Gently insert a prying tool between the bezel and the screen.
• Carefully work around the edges to separate the bezel.
• Attention: The bezel is likely glued with double-sided tape, especially at the bottom.

3. Accessing the Screen:

• Once the bezel is removed, the screen will be exposed.
• The screen is likely held in place by double-sided tape or similar adhesive, not screws.

4. Disconnecting the Screen:

• Locate and carefully disconnect the screen cable.
• You may need to gently lift or move parts to access the connector.
• Handle with care: Avoid damaging the connector and cable.

5. Removing the Old Screen:

• Carefully peel off any tape or adhesive holding the screen.
• Remove the cracked screen from the laptop chassis.

6. Preparing the New Screen:

• Screen Model: Look for a replacement screen with the model number B156HAN13.0 by AU Optronics.
• Adhesive Tape: Use strong double-sided tape (like red adhesive tape) to secure the new screen if the original adhesive isn’t reusable.

7. Installing the New Screen:

• Place the new screen into the chassis.
• Carefully connect the screen cable, ensuring it is secure and not strained.
• Apply the double-sided tape to hold the screen in place firmly.

8. Reattaching the Bezel:

• Align and press the bezel back onto the laptop.
• Ensure it sticks properly to the new screen.

9. Finalizing the Replacement:

• Power on the laptop to test the new screen.
• Check for any display issues or loose connections.

Conclusion

• Screen replacement for the MSI GF65 Thin 9SEXR involves careful handling due to the adhesive and delicate connectors.
• Ensure all connections are secure before finalizing the replacement.
• Test the laptop to confirm the functionality of the new screen.

Additional Notes

• Replacement screens, tools, and adhesive tapes are available online. Links for these can be found in the video description.
• This guide provides a general outline; the video offers more detailed visual instructions.
