MSI Gaming Laptop (MS-160) Screen Replacement Guide

Hi, I’m Simon. In this tutorial, I’ll guide you through replacing the screen on an MSI gaming laptop, model MS-160. This step-by-step guide is aimed at helping you with a DIY screen replacement.

Starting Off

• Laptop Model: MSI MS-160.
• Issue: Cracked screen needing replacement.

Keyboard and Bezel

• Keyboard Overview: Showing the keyboard layout for reference.
• Removing the Bezel: Carefully pry open the bezel using a metal prying tool. It’s clipped on and held by double-sided tape at the bottom.

Removing the Screen

• Screen Removal: No screws, but the screen is glued in with double-sided tape. Carefully cut through the adhesive to free the screen.
• Tape Considerations: The original tape may run along the entire bottom edge. In our case, the tape is only visible at one end, suggesting a past screen replacement.

Disconnecting the Screen

• LCD Connector: Gently remove the securing tape and slide the cable away to disconnect.

Preparing for New Screen

• Model Number: Check your screen’s model number (B156HAN02.1 for this laptop) to order the correct replacement.
• Securing the New Screen: Attach new double-sided tape (5mm width) along the edges where the old screen was attached.

Installing the New Screen

• Connector Attachment: Carefully connect the LCD cable to the new screen and secure it with tape.
• Aligning the Screen: Align the new screen correctly and press down to adhere it via the double-sided tape.

Final Steps

• Reattaching the Bezel: Carefully clip the bezel back into place, ensuring it’s snug and secure.

Conclusion

• Final Thoughts: Screen replacement on MSI gaming laptops is straightforward but requires careful handling. If this guide was helpful, please like and subscribe. Share your experiences or questions in the comments.
• Reminder: Handle your device and its components with care.

That concludes the screen replacement tutorial for the MSI gaming laptop, model MS-160. Thanks for watching, and remember to handle your device with care! See you in the next tutorial.
