Simple Step iPhone 11 Pro Max Screen Replacement

Title: iPhone 11 Pro Max Screen Replacement Tutorial

Author: Simon

Introduction: Hello everyone, Simon here. In this video, I’ll guide you through the process of replacing a cracked screen on an iPhone 11 Pro Max. We’ll be using a full assembly pre-installed screen for this repair. Let’s dive into the steps required to complete this task.

Tools Required:

• Pentalobe P2 screwdriver (0.8 size)
• Tri-point (Y-shaped) screwdriver (0.6 size)
• Phillips screwdriver
• Metal prying tool
• Plastic prying tool

Screen Replacement Process:

1. Removing the Bottom Screws:
   • Use the Pentalobe P2 screwdriver to remove the two screws at the bottom of the iPhone.
2. Opening the Phone:
   • Carefully insert the metal prying tool between the screen and the phone’s chassis.
   • Gently move around the phone’s edge to cut through the adhesive seal.
3. Disconnecting the Battery:
   • Using the tri-point screwdriver, remove the screws and bracket that secure the battery connector.
   • Disconnect the battery using the plastic prying tool.
4. Disconnecting the Screen:
   • Remove the screws and bracket that secure the screen connectors using the tri-point screwdriver.
   • Carefully disconnect the three cables for the ear speaker, proximity sensor, and screen.
5. Transferring Components to the New Screen:
   • Remove the proximity sensor and ear speaker from the old screen.
   • Transfer these components to the new screen assembly.
   • Re-attach using the Phillips screwdriver.
6. Reconnecting the New Screen:
   • Align the new screen and connect the three cables.
   • Secure the connectors with the bracket and screws.
7. Finalizing the Assembly:
   • Reconnect the battery and secure it with its bracket and screws.
   • Carefully close the phone by first aligning the top edge and then gently pressing the screen into place around all edges.
8. Finishing Up:
   • Re-insert the two pentalobe screws at the bottom of the iPhone.

Conclusion: That’s it! You’ve successfully replaced the screen of your iPhone 11 Pro Max. Power on the phone to test the new screen’s functionality.

Closing Remarks: Thank you for watching this tutorial. If you found it helpful, please like, share, and subscribe for more how-to videos. If you have any questions or encounter issues, feel free to leave a comment below. For replacement parts and tools, check the links in the description. Good luck with your repair, and see you next time!

Additional Tips:

• Keep track of all screws during the process, as they come in different sizes.
• Be gentle when handling the cables and connectors to avoid damaging them.
• Ensure the new screen is free from dust and fingerprints before sealing the phone.
• Test all functionalities, including the touchscreen, display, and Face ID, after the repair.
