How to Set Up Your TP-Link AC1200 Router and Configure Port Forwarding for PS5

Hey there, Simon here! Are you looking to set up your TP-Link AC1200 Mesh Wi-Fi Router and ensure your PlayStation 5 has the best possible connection? You’re in the right place! Follow this step-by-step guide to get everything up and running smoothly.

Setting Up the TP-Link AC1200 Router

What You’ll Need:

• TP-Link AC1200 Mesh Wi-Fi Router
• Power Cable
• Internet Service Provider (ISP) Cable
• Laptop or Desktop for Configuration

Step 1: Connect the Cables

• Plug in the power cable on the far right of the router.
• Connect the ISP cable to the blue port on the router.
• Use the yellow ports to connect local devices like your PS5 or desktop.

Step 2: Access the Router’s Settings

• On your laptop or desktop, open a web browser.
• Navigate to tp-linkwifi.net.
• Create a password for your router’s control center.

Step 3: Quick Setup

• Select your time zone.
• Choose ‘Dynamic IP’ for residential setups.
• Enable wireless radio and set your Wi-Fi network name and password.
• Review the settings summary and click ‘Save’.

Configuring Port Forwarding for PlayStation 5

Step 1: Identify Your PS5’s IP Address

• In the router’s dashboard, check under ‘Wired Clients’ or ‘Wireless Clients’ to find your PS5’s IP address.
• Note down this IP address.

Step 2: Access Advanced Settings

• In the router’s dashboard, go to the ‘Advanced’ tab.
• Scroll to ‘NAT Forwarding’ and select ‘Virtual Server’.

Step 3: Add Ports for PS5

Add the following ports with your PS5’s IP address:

1. Port 1935 (TCP/UDP)
   • External Port: 1935
   • Internal Port: 1935
2. Port 3074 (TCP/UDP)
   • External Port: 3074
   • Internal Port: 3074
3. Port 3478 (TCP/UDP)
   • External Port: 3478
   • Internal Port: 3478
4. Port 3479 (TCP/UDP)
   • External Port: 3479
   • Internal Port: 3479
5. Port 3480 (TCP/UDP)
   • External Port: 3480
   • Internal Port: 3480

After each entry, click ‘Save’.

Conclusion

That’s it! Your TP-Link AC1200 router is now set up, and your PS5 is ready to deliver the best gaming experience with the necessary ports forwarded. If you found this guide helpful, please like, subscribe, and hit the notification bell for more tech tips. Have questions? Drop them in the comments below, and I’ll get back to you promptly. Happy gaming, and remember, there’s always something new to learn!
