Title: Upgrading Your Acer Nitro 5 Gaming Laptop: A Step-by-Step Guide
Introduction: Welcome! I’m here to guide you through upgrading various components of your Acer Nitro 5 gaming laptop (Model AN515, N20C1). This comprehensive tutorial covers upgrading RAM, the M.2 drive, replacing the battery, and changing the CPU fan.
Tools Required:
- A Phillips screwdriver (electric or manual).
Procedure:
- Unscrewing the Back Cover:
- Begin by removing all screws from the back cover using the Phillips screwdriver.
- Opening the Laptop:
- Carefully pry open the back cover using a metal prying tool to initiate and a plastic tool to avoid scratches.
- Internal Overview:
- Inside, you’ll find the battery, M.2 drive, Wi-Fi card, CPU fans, heatsinks, DDR4 RAM, and the motherboard.
- Disconnecting the Battery:
- To safely proceed, disconnect the battery by sliding its connector downwards.
- RAM Upgrade:
- The laptop has two RAM slots. Upgrade by adding additional DDR4 RAM sticks as needed.
- Replacing the M.2 Drive:
- Remove the existing M.2 drive by sliding it gently to the left. It can be upgraded to a larger capacity drive if required.
- Wi-Fi Card and CMOS Battery:
- Disconnect the Wi-Fi antennas and slide out the card. If resetting BIOS settings is necessary, disconnect the CMOS battery.
- Disconnecting Other Components:
- Carefully disconnect cables connected to the motherboard, including the keyboard, touchpad, and LCD screen cables.
- Removing the CPU Fans and Heatsink:
- Uninstall the CPU fans and heatsink by unscrewing and carefully lifting them off.
- Motherboard Removal:
- Carefully remove the motherboard by unscrewing and gently lifting it out of the chassis.
- LCD Hinges and Keyboard Assembly:
- Unfasten the screws holding the LCD hinges. Open the hinges at a 90-degree angle to remove the entire keyboard assembly.
Conclusion: The Acer Nitro 5 offers a straightforward path for upgrading key components to enhance your gaming experience. Remember, the keyboard is part of a full assembly and can’t be replaced individually. If you have any questions or need assistance, feel free to drop a comment below. Happy upgrading!
Additional Resources:
- For tools and replacement parts, check the links in the description, directing you to Amazon or eBay.
- Also, explore our separate video benchmarking the Acer Nitro 5 to understand its performance capabilities better.
