How to Replace a Damaged Screen on Dell Latitude 5490

Hello there! Simon here, hoping you’re all doing well. If you’ve stumbled upon this post, chances are, you’re looking to replace a cracked or pixelated screen on your Dell Latitude 5490. Today, I’ll be guiding you step-by-step to ensure a smooth replacement process.

1. Identifying the Problem

When the screen displays irregular patterns, pixelation, or obvious cracks, it’s time for a replacement. Before you start, ensure your computer is turned off. Hold down the power button until it completely shuts down.

2. Safety First – Removing the Battery

It’s recommended to disconnect the battery before doing any hardware modifications. Here’s how:

• Tools Needed: A Phillips screwdriver.
• Procedure:
  • Begin by unscrewing the back cover. The top screws might not come off completely, but ensure they’re loosened.
  • Carefully pop open the back using the opening gap for the SD card or by getting in between the plastic connectors.
  • Once opened, you’ll find the battery connector. Lift it straight up to disconnect.

3. Screen Removal

The most critical step. Here’s a breakdown:

• Tools Needed: Your hands and some patience.
• Procedure:
  • Start by peeling off the bezel, which is held down by adhesive tape.
  • Be cautious around the front camera and microphones.
  • With the bezel off, you’ll notice screws holding the screen. Unscrew the ones on the top corners and the bottom.
  • Tilt the screen gently towards the laptop’s body to expose the connector tape. Peel this tape backward but avoid yanking or ripping the cables.
  • Disconnect the screen’s connector.

4. Replacement

Now, the main event.

• Tools Needed: The replacement screen.
• Procedure:
  • With the new screen, connect the cable by sliding it in, ensuring the metal clipper is open.
  • Push the connector all the way in and clip it down. Reinforce with the blue tape.
  • Position the screen and screw it back in.
  • If your bezel’s adhesive isn’t sticky enough, use 3mm double-sided adhesive tape.
  • Finally, reconnect the battery and screw back the back cover.

Conclusion

Power up your laptop, and voila! You should now be greeted by a pristine, new screen. If this guide was helpful, do leave a like and comment. For those wondering about where to buy the right screen or tools, check out the links in the description.

Also, if you wish to support the content, consider checking out the YouTube TS or my PayPal. Every bit helps and is greatly appreciated!

Until next time, happy computing!
