Title: Electronics Laptop Teardown Tutorial
Video Description:
In this tutorial, Simon performs a teardown of an Electronics MX17 laptop. He demonstrates how to access the internal components of the laptop, such as the RAM, M.2 SSD drives, battery, fans, and heat sink. The video is beneficial for those looking to upgrade their laptop or diagnose hardware issues.
Key Steps in the Video:
- Removing the Back Cover:
- Simon uses a Phillips screwdriver to remove all the screws securing the back cover. He then pries open the cover to reveal the laptop’s internal components.
- Accessing RAM and M.2 SSD Drives:
- He points out the locations of the DDR4 RAM slots and the M.2 SSD slots. The laptop has two RAM slots (both removed for the demonstration) and two M.2 SSD slots (also removed).
- Disconnecting the Battery:
- Simon disconnects the battery by sliding its connector away from the body of the laptop and then removes the battery.
- Removing the CMOS Battery:
- The CMOS battery is removed by sliding its connector to the right.
- Disconnecting the Wi-Fi and Speaker Cables:
- He disconnects the Wi-Fi cables (grey and black) and the speaker connector by sliding them in the appropriate directions.
- Disconnecting and Removing the CPU Fans and Heat Sink:
- The CPU fan connectors are disconnected by sliding them to the left and right. Simon then removes the screws holding the heat sink and fans in place, taking out the entire assembly. He notes a burn mark on the motherboard under the thermal pad, indicating a possible issue.
- Observations on the Keyboard:
- Simon observes that the keyboard is not easily replaceable as it is integrated into the laptop’s chassis. However, he suggests that the entire top assembly, including hinges, could be replaced if necessary.
- Conclusion:
- The video concludes with Simon reassembling the laptop after identifying a potential motherboard issue due to the burn mark. He recommends where to find replacement parts and tools for such repairs.
