How to Replace a Screen on an MSI Gaming Laptop (MS-16 K2)

Introduction

• Host: Simon
• Problem: Screen backlighting issues, can also be used if the screen is pixelated, fuzzy, or cracked.
• Model: MSI ms-16 K2

Steps:

1. Preparation: Ensure the computer is completely powered off. Though it’s recommended, Simon chose not to disconnect the battery for this demonstration.
2. Removing the Bezel:
   • Use a metal prying tool to separate the adhesive between the screen and the bezel. This adhesive is a double-sided tape.
   • As you’re cutting through, you’ll notice some of the tape comes off.
   • The bezel around the webcam area can be particularly tricky. Be very careful around the webcam and its associated cables.
   • The adhesive tape can be very sticky and may seem like glue in certain parts.
3. Preparing for the New Screen:
   • Once the bezel is removed, check if the screen is held by screws or adhesive.
   • In Simon’s case, the screen was held by four Phillips screws (2 at the top and 2 at the bottom). Remove these screws.
   • Carefully tilt the screen towards you. Note that there’s a cable still connected to it.
   • Gently disconnect this cable. Slide the connector away from the body to remove the screen.
4. Identifying the Screen Model:
   • For replacement purposes, Simon’s old screen model was “N156HGE-RV.C1”. Check the back of your screen for its model.
5. Installing the New Screen:
   • Connect the cable to the new screen. Ensure it’s firmly secured.
   • Place the screen in its original position.
   • Make sure cables are managed well and are not protruding out.
   • Screw the new screen into place using the four Phillips screws.
6. Applying Double-Sided Tape:
   • Prepare the double-sided tape. Simon used 5mm tape, but you can choose the size that suits your laptop.
   • Apply this tape to the areas where the original adhesive was.
   • Make sure the area is clean for better adhesion. (Simon skipped thorough cleaning for the sake of the video demo).
7. Attaching the Bezel:
   • Before you attach the bezel, peel off any protective film from the new screen.
   • Carefully position the bezel, ensuring it aligns with the webcam and other components.
   • Press down on the bezel, especially around the edges, to ensure it sticks well.
8. Testing:
   • Power on the computer to check if the screen is working. In Simon’s case, the screen appeared dim, indicating further diagnostics were needed for his laptop.

Conclusion: Replacing the screen of an MSI Gaming laptop is a straightforward process if you have the right tools and follow the steps carefully. Make sure to check links provided by the host for replacement parts or further assistance.
