How to Replace the Charging Port on a Dell Inspiron 3593 Laptop
By Simon
1. Introduction:
- Welcome to this video. Today we will be replacing the damaged charging port on a Dell Inspiron 3593 laptop.
2. Identifying the Model:
- Turn the laptop over, and you will find the model identifier, which in this case is Inspiron 3593 or P75 F.
3. Tools Needed:
- Phillips screwdriver (PH1).
- Metal prying tool.
- Plastic prying tool.
4. Opening the Laptop:
- There are three screws at the top that do not come out. Do not over-turn them.
- Three screws in the middle do come out.
- Three screws at the bottom, including a smaller screw in the center, also come out.
- Use the metal prying tool to create a gap between the base and the back cover.
- Then switch to the plastic prying tool to further separate without damaging the laptop.
5. Replacing the DC Jack:
- Focus on the top-right corner; the hinge covers the DC jack.
- Remove the three screws holding the hinge.
- Lift the hinge to expose the DC jack.
- Remove the screw holding the DC jack.
- Slide the jack connector away from you.
- The damaged jack can be distinguished by its broken plastic exterior. Remove it.
- Replace with the new jack.
- Ensure the connector aligns correctly; the gold-plated side should face down.
- Secure the jack with its screw and make sure the cable stays inside.
- Close the hinge and secure with the three screws.
6. Closing Up:
- To reinstall the back cover, tuck in the edges first and press down to snap into place.
- Put back all screws.
7. Testing:
- Plug in the charger.
- There should be a light or an indication that the laptop is charging. If it’s too bright, you might need to shade the area to see the light.
8. Conclusion:
- This is how you replace the DC jack for the Dell Inspiron 3593.
- If you found the video helpful, please like and subscribe.
- If you wish to support the channel, consider donating through YouTube super thanks.
- Thanks for watching, and take care!
Note: This is a summarized guide based on the transcription provided. Always refer back to the original video when performing the procedure to ensure all steps are correctly followed.
