How to Replace the Motherboard in an HP 550-110 PC
Welcome back to my channel! On this special Friday 13, 2017, we faced a challenging situation – a BIOS update that turned the screen black and rendered the computer inoperable. After various tests, it was determined that the motherboard needed to be replaced. Here’s a step-by-step guide based on my experience.
Requirements:
- Screwdriver
- New motherboard
- Your HP 550-110 PC
Steps:
1. Unplug all cables from the back of your computer.
2. Disconnect the power supply and the 24-pin connector.
3. Remove other connections such as:
- SATA cables (hard drive, optical drive)
- USB cables, including USB 3.0 from the front
- Audio cables
- Wi-Fi connections (which we’ll revisit later)
4. Before delving deep into the motherboard, remove some external components:
- CPU heatsink
- Exhaust fan
- Power switch, front lights, and power buttons
5. Unscrew and remove the motherboard. The HP 550-110 has 9 screws in total.
6. Take out the hard drive if it obstructs the last screw.
7. Once you’ve removed the motherboard, transfer the CPU and RAM to the new motherboard. Remember to handle the CPU with care.
8. Gently place the new motherboard in the PC case. Align the motherboard, ensuring the back ports (USB, HDMI, etc.) fit into their respective spaces in the case.
9. Start screwing in the motherboard from the center, gradually moving outwards. Don’t tighten screws completely until all screws are aligned properly.
10. Reconnect the components in reverse order:
- SATA cables
- Audio and USB cables
- Power switch, front lights, and power buttons
- CPU and heatsink
- Exhaust fan
11. Remember to connect the Wi-Fi component.
12. Before sealing everything up, conduct a test run. Power on the computer to ensure the new motherboard works and displays an output. For safety reasons, do not touch internal components while the power is on.
Conclusion:
The motherboard replacement should resolve the black screen issue after a BIOS update. Always handle components with care, and remember to conduct a thorough test before sealing everything up. Don’t replicate any shortcuts that might jeopardize safety. If you found this guide helpful, please like, share, and subscribe! Thanks for watching.
