itle: Repairing a Broken Hinge on HP Envy 14 Laptop

Introduction:

Hi, Simon here! In this video, we’re going to tackle a common issue with laptops – a broken hinge. Specifically, we’re dealing with an HP Envy 14 model (14m-dy0033dx), where the hinge has caused the screen to separate. Ideally, a full assembly replacement is recommended, but due to the unavailability of parts, we’ll compromise by replacing just the top cover.

Tools and Materials Needed:

• Metal prying tool
• Replacement top cover for HP Envy 14
• Double-sided adhesive tape (5 mm)
• Phillips screwdriver

Step-by-Step Guide:

1. Initial Assessment: The client tried using electric tape to hold down the broken hinge, but it wasn’t effective. The screen and glass have separated due to the hinge breaking off.
2. Battery Disconnection: Start by removing the back cover and disconnect the battery. Slide the battery connector to the right to safely disconnect it.
3. Removing the Screen: Gently open the laptop. The screen might be misaligned due to the broken hinge. Remove any temporary fixes like electric tape used by the client.
4. Separating the Screen: Use a metal prying tool to create room to work with. The goal is to gently separate the screen from the double-sided adhesive tape holding it.
5. Transferring Components: Carefully transfer essential components like the Wi-Fi antennas and the webcam from the broken top cover to the new one. Be gentle with the webcam as it is attached to a silver lining tape.
6. Removing and Reattaching Hinges: Unscrew the hinges (three screws each side) from the old cover and attach them to the new cover. Ensure they are screwed in firmly.
7. Reapplying the Screen: Use a 5 mm double-sided tape to reattach the screen to the new top cover. Apply the tape evenly and press down the screen to ensure it sticks properly.
8. Reconnecting Components: Make sure to reattach the Wi-Fi antennas and webcam cables correctly. These components are crucial for the laptop’s functionality.
9. Final Assembly: After ensuring everything is in place, reattach the battery connector. Then, close the laptop to check if the screen closes and opens smoothly.
10. Screwing the Back Cover: Put the back cover on and screw it back into place.

Conclusion:

And that’s how you fix a broken hinge on an HP Envy 14 laptop by replacing the top cover. While it’s not the ideal full assembly replacement, it’s a practical solution when specific parts are not available. If you found this guide helpful, please consider giving a like and subscribing for more tutorials. For donations, you can use the Super Thanks feature on YouTube. Thanks for watching, and see you in the next repair guide!
