Step-by-Step Guide to iPhone 7 Plus Screen Replacement

Replacing the screen on an iPhone 7 Plus can be a bit tricky, but with the right tools and careful handling, it’s definitely doable. Here’s a detailed guide to help you through the process.

Tools Needed

• Pentalobe screwdriver
• Philips screwdriver
• Plastic pry tool
• New iPhone 7 Plus screen assembly
• Heat gun or hairdryer (optional)

Procedure

1. Turn Off the Phone: Ensure your iPhone 7 Plus is completely powered down.
2. Remove Bottom Screws:
   • Use the Pentalobe screwdriver to remove the two screws next to the charging port.
3. Opening the Screen:
   • Optionally, use a heat gun or hairdryer to gently warm the edges. This step helps in loosening the adhesive.
   • Insert a plastic pry tool between the screen and the phone’s body.
   • Gently slide around the edges to cut through the adhesive.
4. Lifting the Screen:
   • Open the screen to about a 90-degree angle. Be careful not to pull it too far to avoid damaging the flex cables.
5. Removing the Bracket:
   • Use the Philips screwdriver to remove the four screws securing the metal bracket over the screen connectors.
   • Remove the bracket and disconnect the screen’s flex cables using the plastic pry tool.
6. Transferring Components:
   • Remove the home button from the old screen and carefully transfer it to the new screen.
   • Transfer the front camera and the speaker from the old screen to the new screen.
7. Reconnecting the New Screen:
   • Connect the flex cables of the new screen to the motherboard.
   • Replace the metal bracket and secure it with the screws.
8. Reassembling the Phone:
   • Carefully align the screen onto the phone’s body, starting from the top. Gently press down around the edges to re-adhere the screen.
   • Reinsert and tighten the two Pentalobe screws near the charging port.
9. Testing the New Screen:
   • Power on your iPhone 7 Plus to test the new screen. Ensure the touch functionality and display are working correctly.

Conclusion

Screen replacement for the iPhone 7 Plus requires careful handling, especially when transferring delicate components like the home button and front camera. If the screen doesn’t function correctly after installation or if you encounter difficulties, seeking professional help is recommended. For tools and screen purchasing options, refer to the video description.
