Step-by-Step Guide to Replacing a MacBook Air 2017 LCD Screen
Replacing an LCD screen on a MacBook Air can seem intimidating, but with the right tools and guidance, it’s a manageable task. Today, we’re focusing on a MacBook Air 2017 model, where the entire LCD unit, along with the top cover, needs replacement.
Tools Required
- Pentalobe Screwdriver
- Torx Screwdrivers (T8 and T12)
- Plastic Pry Tool
- Tweezers
Steps for Replacing the LCD Screen
- Turn Off the MacBook: Ensure the device is completely powered down before you begin.
- Remove the Back Plate: Unscrew all the screws using the pentalobe screwdriver. Carefully lift and set aside the back plate.
- Disconnect the Battery: For safety, disconnect the battery by gently prying the connector.
- Remove Additional Components: If required, disconnect the DC jack/power charger component and the speakers to access the screen connectors.
- Loosen the Motherboard: Use the appropriate torx screwdrivers to loosen the motherboard slightly. This step is crucial for safely removing the LCD screen without damaging the connectors.
- Remove the LCD Connectors: Carefully open the clippers holding the LCD cables and gently disconnect them. Ensure you’re using a plastic tool to prevent any electrical shorts.
- Unscrew the LCD Hinges: Position the MacBook at about a 90-degree angle for easier access to the hinges. Use a Torx T8 screwdriver to unscrew the six screws (three on each side) holding the LCD screen.
- Detach the Old Screen: Carefully lift and remove the damaged screen.
- Install the New LCD Screen: Position the new screen at a 90-degree angle and slide it into the hinges. Secure it with at least one screw on each side before carefully closing the MacBook to complete the screwing process.
- Reconnect the Components: Reattach all previously disconnected components, including the LCD connectors, DC jack, and speakers. Ensure all cables are correctly positioned and secured.
- Reinstall the Fan: If you removed the fan, reconnect it along with its cables, ensuring everything is correctly aligned and secured.
- Reconnect the Battery: Carefully reconnect the battery, ensuring the connector is properly aligned and secure.
- Test the New Screen: Before reassembling completely, power on your MacBook to test the new screen.
- Reassemble the MacBook: Once you’ve confirmed the new screen is working, turn off the MacBook and reattach the back plate. Screw in all the screws, and replace any rubber feet if they were removed.
Conclusion
Replacing an LCD screen on a MacBook Air requires patience and attention to detail. However, with the right tools and careful following of these steps, it’s a task that can be accomplished at home.
Remember, if you find this tutorial helpful, consider subscribing to the channel for more tech DIYs and troubleshooting guides. If you have any questions or run into issues during your repair, feel free to drop a comment below. Happy repairing!
