Guide to MacBook Pro (2020) Screen Replacement (Model A2338 M1)
Introduction
- Objective: Tutorial on replacing the screen of a 2020 MacBook Pro (Model A2338 M1).
- Tools Needed: Pentalobe P5 screwdriver, T4 screwdriver, metal prying tool, replacement screen.
Steps for Screen Replacement
- Removing the Back Cover:
- Use Pentalobe P5 screwdriver to remove screws from the back cover.
- Use a metal prying tool to gently release side clippers.
- Slide the back cover down towards you to remove it.
- Disconnecting the Battery:
- Peel off the plastic cover over the battery connector.
- Open the safety clipper and slide the flex cable to the left to disconnect the battery.
- Use a T4 screwdriver to remove the screw securing the battery.
- Accessing the Screen:
- Remove additional screws at the bottom using a T4 screwdriver.
- Remove the bracket covering the screen connectors.
- Carefully disconnect the screen connectors.
- Removing the Screen:
- Use a T4 screwdriver to remove screws holding the Wi-Fi antenna.
- Use a Pentalobe P2 (0.8) screwdriver to remove tiny screws securing the Wi-Fi antenna bar.
- Remove the Wi-Fi antenna and disconnect it from the motherboard.
- Use a T8 screwdriver to remove screws from the hinges.
- Open the laptop and slide the hinges out to remove the screen.
- Installing the New Screen:
- Open the hinges on the new screen.
- Align and slide the hinges back into the laptop base.
- Secure the hinges with screws using a T8 screwdriver.
- Reconnecting Components:
- Reattach the Wi-Fi antenna and secure it with screws.
- Reconnect the screen connectors and replace the protective bracket.
- Reconnect the battery and secure it with the screw.
- Finalizing Installation:
- Carefully align and slide the back cover into place.
- Secure the back cover with screws using the Pentalobe P5 screwdriver.
Tips and Precautions
- Handling Connectors: Be gentle with flex cables and connectors to avoid damage.
- Screw Tracking: Keep track of screws and their corresponding locations.
- Battery Safety: Avoid constantly charging the battery to prevent issues.
- Test Before Finalizing: Before securing the back cover, test the screen to ensure it’s working.
Conclusion
- Model Specific: This guide is specific to the MacBook Pro 2020 Model A2338 M1.
- Support: For further assistance, viewers are encouraged to comment below.
Additional Notes
- Power Requirement: After screen replacement, the MacBook may require connection to a power adapter to start up.
- Tool and Part Links: Links for purchasing tools and the replacement screen are provided in the video description.
