Simon’s video is a step-by-step tutorial on disassembling an MSI gaming laptop, specifically the model MS-16J9, which dates back to 2017 or 2018. Here are the main points he covered:
- Identification: Check the back of the laptop for the model number. In this case, it’s MS-16J9.
- Required Tool: A Phillips screwdriver (PH1 and 1.5 for smaller screws) is essential.
- Documenting Screw Locations: He suggests photographing the laptop and using the printout as a reference for screw placement when reassembling.
- Disassembly Steps:
- Remove all the screws from the laptop’s back cover.
- Slide the optical drive to the left to access three hidden screws.
- Once all screws are out, gently pry open the back cover.
- Remove the built-in battery, identifying it as a 246 cells battery with model number BTY-M6H.
- Highlighted the locations and removal processes of the following components:
- M.2 Hard Drive
- DDR4 RAM
- Additional slot for a 2.5-inch hard drive
- Heatsink and CPU fan
- Described the removal of the Wi-Fi card, its wires, and CPU fan connector.
- Emphasized the correct reconnection of the CPU fan based on the connector’s design.
- Pointed out the CMOS battery, the connector for the speaker, and cables for USB ports and touchpad.
- Discussed the removal of the heatsink, which is attached to both the CPU and GPU.
- Removed the DC jack connector and described how to separate the keyboard and screen from the motherboard by adjusting the hinges.
- Notes:
- Simon mentions the importance of being gentle when prying components to prevent damage.
- He pointed out that the keyboard is not replaceable due to the manufacturer’s design.
The video seems to serve as a handy guide for anyone looking to disassemble this specific MSI laptop model, whether for repairs, upgrades, or simple curiosity.
