Title: CPU Fan Cleaning and Thermal Paste Application in MSI GS56 Stealth

Introduction:

Hi everyone, Simon here! Today, I’m going to guide you through cleaning out a CPU fan and applying new thermal paste in an MSI GS56 Stealth gaming laptop. This process is crucial for maintaining optimal thermal performance and ensuring the longevity of your laptop.

Tools and Materials Needed:

• Phillips screwdriver
• New thermal paste
• Alcohol wipes

Step-by-Step Guide:

1. Removing the Back Cover: Start by unscrewing the back cover with a Phillips screwdriver. The screws are generally of the same size, except for the one in the middle at the bottom, which is shorter. Note that breaking the factory seal sticker may void the warranty, so proceed with caution.
2. Battery Disconnection: To prevent any electrical mishaps, disconnect the battery by sliding its connector downwards towards your body.
3. Wi-Fi Cables: Mark the Wi-Fi cables if they are not color-coded for easy reassembly. Carefully detach them by pulling straight upwards.
4. Heatsink Screws Removal: Remove the screws holding the heatsink in place. Be cautious and do not mix match the screws. There are different screws for the heatsink and the CPU area.
5. Detaching the Heatsink: Gently lift the heatsink. Give it time to separate from the thermal paste and thermal pads. Avoid applying too much pressure to prevent damage.
6. Cleaning the Old Thermal Paste: Use alcohol wipes to clean off the old thermal paste from both the CPU and the GPU areas. Ensure no paste residue falls onto the motherboard.
7. Applying New Thermal Paste: Apply a small amount of new thermal paste on the CPU and GPU. A little X or a few dots across the GPU are usually sufficient to spread evenly once the heatsink is reattached.
8. Cleaning the CPU Fan: Use an air duster to clean the CPU fan outside your workspace to avoid spreading dust.
9. Reassembling the Heatsink: Carefully reposition the heatsink onto the CPU and GPU, ensuring all cables are properly placed above the heatsink. Screw the heatsink back into place.
10. Reconnecting Components: Reconnect all cables, including the CPU fan connector and Wi-Fi cables, and slide the battery connector back into place.
11. Closing the Laptop: Once everything is in place, close the back cover and screw it back on. Remember, the shortest screw goes in the middle at the bottom.

Conclusion:

And that’s it! You’ve successfully cleaned the CPU fan and applied new thermal paste to your MSI GS56 Stealth. This should help keep your laptop running cool and efficiently. If you found this guide helpful, please consider showing your appreciation with a Super Thanks on YouTube. Don’t forget to hit the like button and subscribe for more tutorials. Thanks for watching, and see you in the next guide!
