Title: MSI PS63 Modern Laptop Teardown Tutorial
Video Description:
In this tutorial, Simon performs a teardown of an MSI PS63 Modern laptop (model MS-16S1). The process demonstrates how to access and upgrade various components like M2 drives, RAM, battery, and fans. This video is ideal for anyone looking to upgrade their laptop or replace specific parts.
Key Steps in the Video:
- Removing the Back Cover:
- Simon uses a Phillips screwdriver to remove all the screws securing the back cover, including one hidden behind the factory seal sticker.
- Identifying Internal Components:
- He points out the CPU fans, M2 NVMe drive, DDR4 RAM, CMOS battery, laptop battery, Wi-Fi card, and the logic board.
- Disconnecting and Removing the Battery:
- The battery connector is slid down towards the body, and then the battery is unscrewed and removed.
- Removing M2 Drive:
- The M2 drive is unscrewed, lifted at a 45-degree angle, and slid out. Simon notes the presence of thermal pads on the M2 drive.
- Removing RAM:
- The clips on either side of the RAM are opened, allowing the RAM to be easily removed.
- Disconnecting CMOS Battery:
- The CMOS battery connector is slid to the left for disconnection.
- Disconnecting Fans and Removing Heat Sink:
- Simon disconnects the CPU fan connectors and proceeds to unscrew and remove the heat sink, which includes the fans.
- Observations on Thermal Pads and Paste:
- He observes the use of thermal pads and liquid thermal paste on the CPU and suggests replacing them if the laptop has overheating issues.
- Disconnecting Motherboard:
- Various connectors on the motherboard are disconnected, including those for the keyboard, speakers, LCD screen, and CPU fans.
- Motherboard Removal:
- Simon carefully removes the screws securing the motherboard and then carefully lifts the motherboard, noting that the keyboard is still attached to it.
- Keyboard Replacement Note:
- He explains that the keyboard is non-replaceable due to its integration with the laptop’s chassis. A complete top assembly replacement is required to replace the keyboard.
- Conclusion:
- The video concludes with Simon reassembling the laptop. He recommends checking the video description for links to replacement parts and tools.
