Title: Installing an Additional 1TB M.2 NVMe SSD on Acer Predator Helios 300

Introduction:

Welcome! I’m Simon, and in this video, I’ll guide you through adding a secondary 1TB M.2 NVMe SSD drive to an Acer Predator Helios 300 laptop. This upgrade is perfect for increasing your storage capacity for gaming or heavy-duty tasks.

Materials Needed:

• 1TB M.2 NVMe SSD Drive.
• Phillips screwdriver.

Steps for M.2 SSD Installation:

1. Removing the Back Cover:
   • Use the Phillips screwdriver to remove all screws from the back cover. In this model, all screws are the same size, so mixing them is fine.
   • After removing the screws, use a metal prying tool to gently pry open the back cover from the side corner.
   • Slide the back cover away from the body, taking care not to damage the ports attached to it.
2. Installing the M.2 SSD:
   • Before handling internal components, disconnect the battery by sliding the connector downwards.
   • Locate the secondary M.2 slot (next to the pre-installed M.2 SSD).
   • Insert the new M.2 SSD at a 45-degree angle and secure it with the screw provided.
   • Reconnect the battery by sliding the connector back into place.
3. Reassembling the Laptop:
   • Slide the back cover back into place, starting from the top to align with the ports.
   • Press down to secure the cover and replace all the screws.
4. Initializing and Formatting the New SSD:
   • Turn on your laptop.
   • Right-click on the Start button and select ‘Disk Management’.
   • In Disk Management, the new SSD will show as ‘Not Initialized’ and ‘Unallocated’.
   • Right-click on the new SSD, select ‘Initialize Disk’, and follow the prompts.
   • After initializing, right-click on the unallocated space, select ‘New Simple Volume’, and follow the setup wizard.
   • Assign a drive letter and format the SSD to NTFS. You can also name the volume (e.g., ‘1TB Data Drive’).
5. Verifying the New SSD:
   • Go to ‘This PC’ to confirm the new SSD is recognized and accessible.

Conclusion:

Upgrading your Acer Predator Helios 300 with a secondary 1TB M.2 NVMe SSD is a great way to expand your storage space. The process is relatively simple and can be done with basic tools.

Additional Tips:

• Ensure the laptop is off and disconnected from power before starting.
• Handle the SSD and other internal components with care to avoid static damage.
• After the upgrade, your laptop will be better suited for storing large files, games, or software.
