Title: Acer Predator Triton 500 SE Teardown and SSD Replacement Guide
Introduction:
Hi, Simon here! In today’s guide, we will be doing a complete teardown of the Acer Predator Triton 500 SE. This tutorial will cover how to remove the hard drive, potentially change the RAM, and replace the battery. I’ll also be replacing the SSD in this video, so let’s get started.
Tools You’ll Need:
- A Torx T8 screwdriver
- A Phillips screwdriver
- Metal and plastic prying tools
Teardown Steps:
- Removing the Back Cover: Start by using the T8 screwdriver to remove all the screws on the back cover. The screws are of the same size, so it’s okay to mix them up. Use the metal prying tool to gently lift the back cover, and then switch to a plastic prying tool to avoid scratches.
- Disconnecting the Battery: Remove the tape holding down the battery connector and slide it down towards your body to disconnect it.
- Removing Components:
- Keyboard and trackpad connectors: Open the clippers and slide the cables out.
- Wi-Fi card: Lift the antenna cables, unscrew the card, and slide it out.
- Speakers: Slide their connectors out.
- CPU fans: Disconnect by sliding the connectors away from your body.
- Motherboard Removal: Disconnect the LCD cable, making sure to remove any clippers or tape holding it down. Unscrew the motherboard and lift it out gently, ensuring no cables are snagged.
- RAM and SSD Replacement:
- The RAM is located on the reverse side of the motherboard. To replace it, release the clippers and lift the RAM sticks out at a 45-degree angle.
- For the SSD, unscrew the M.2 NVMe SSD drive, replace it with a new one, and screw it back in place.
- Reassembly: Reverse the disassembly steps, ensuring all components are securely reconnected. Pay special attention to aligning the Wi-Fi antennas and properly seating the battery.
- Final Steps: Once reassembled, you’ll need to install an operating system on the new SSD. Use a USB Windows installer, which can be downloaded from Microsoft or purchased with a license key.
Conclusion:
Replacing the SSD in an Acer Predator Triton 500 SE is a straightforward process if you have the right tools and follow the steps carefully. Remember to handle components gently and ensure all connections are secure during reassembly. If you found this video helpful, please consider showing your appreciation with a Super Thanks on YouTube. Don’t forget to hit the like button and subscribe for more tutorials. Thanks for watching, and see you in the next guide!
