Title: How to Set Up a Wireless POE Camera System Using Ubiquiti NanoStation M5

Introduction: Hi there, Simon here! In this guide, I’ll walk you through setting up a wireless POE (Power Over Ethernet) camera system using Ubiquiti NanoStation M5. This setup is perfect for extending your camera network from one building to another without the need for running extensive cabling.

What You’ll Need:

• 2 Ubiquiti NanoStation M5 devices
• 1 Unmanaged POE switch (like the Netgear model I used)
• POE cameras (e.g., Reolink 4K high-resolution cameras)
• Ethernet cables
• A computer for setup

Setup Overview: The idea is to create a wireless bridge between two buildings (A and B) using the NanoStations. Building A, with the main NVR (Network Video Recorder) system, will act as the access point, while Building B, where additional cameras are needed, will be the receiving station.

Step-by-Step Guide:

1. Configure the Access Point (Building A):
   • Connect the NanoStation M5 at Building A to your computer and assign a static IP.
   • Access the NanoStation’s settings via browser (192.168.1.20) and configure it as an access point with the SSID ‘Hello’.
   • Set the security to WPA2 and apply a password (e.g., 123456789).
2. Configure the Station (Building B):
   • Repeat the process with Building B’s NanoStation, setting it as a ‘Station’ that connects to the ‘Hello’ SSID.
   • Ensure both the access point and station are properly configured and communicating.
3. Setting Up the POE Switch and Cameras at Building B:
   • Connect the Station NanoStation M5 at Building B to the POE switch.
   • Connect your POE cameras to the switch. These cameras will now receive power and network connectivity through the switch, linked wirelessly to Building A’s network.
4. Finalizing Network Settings:
   • Revert your computer’s network settings to default (dynamic IP).
   • Connect the Access Point NanoStation in Building A to the NVR system.

Conclusion: You now have a seamless wireless POE camera system connecting two separate buildings. This setup avoids the need for extensive cabling and allows for easier expansion of your camera network.

Additional Tips:

• For purchasing the NanoStation M5, POE switch, or cameras, check the links in the description for direct access to the products on Amazon.
• If you encounter any issues or need more detailed guidance, don’t hesitate to reach out in the comments or contact me directly at 808-236-4335.
