Title: Setting Up Ubiquiti NanoStation M5 for a Point-to-Point Connection

Introduction: Hello everyone, Simon here! In this post, I’ll guide you step-by-step on setting up Ubiquiti NanoStation M5 for a point-to-point connection. This powerful device can provide internet connectivity across buildings up to 10 kilometers apart, with speeds up to 150 Mbps.

What You Need:

• 2 Ubiquiti NanoStation M5 devices
• Ethernet cables
• Power over Ethernet (PoE) injectors (included in the box)

Understanding the Concept: Picture this: you have two buildings, A and B. Building A has an internet connection, and you want to extend this to Building B without paying for an additional ISP subscription. The NanoStation M5 acts as a bridge, with one unit as the Access Point (AP) in Building A and the other as the Station in Building B.

Unboxing: Each NanoStation M5 box contains the device itself, a manual, zip ties, and a PoE injector.

Setup Process:

1. Labeling and Powering Up:
   • Label one NanoStation as the AP (Building A) and the other as the Station (Building B).
   • Connect each NanoStation to its PoE injector and plug into a power outlet.
2. Configuring the Access Point:
   • Connect the AP NanoStation to your computer using an Ethernet cable.
   • Open your browser and enter the default IP address: 192.168.1.20.
   • Log in using ‘ubnt’ for both username and password.
   • In the system settings, rename the device (e.g., ‘A Building’), set your time zone, and change the default password.
   • Under the Wireless settings, set the mode to ‘Access Point’, name your SSID (e.g., ‘Hello’), and adjust the channel width and power output.
   • Set up wireless security with WPA2 and a strong password.
   • In Network settings, select DHCP and apply changes.
3. Configuring the Station:
   • Switch the Ethernet cable from the AP to the Station NanoStation.
   • Repeat the browser login process.
   • Rename the device (e.g., ‘B Building’).
   • In Wireless settings, select ‘Station’ mode and connect to the AP’s SSID (‘Hello’).
   • Enter the password for ‘Hello’ SSID.
   • Select DHCP in Network settings and apply changes.
4. Finalizing Network Settings:
   • Disconnect the Ethernet cable from your computer.
   • Connect the AP NanoStation to your main router or ISP source via the LAN port.
   • The Station NanoStation can now be connected to a router, PC, or any device requiring internet in Building B.

Conclusion: The Ubiquiti NanoStation M5 setup for point-to-point connection is ideal for extending your internet connectivity to remote buildings without the extra cost of a separate ISP. This setup is versatile and can be used for various applications like connecting a distant barn, workshop, or surveillance cameras.
