Acer Aspire C24 Disassemble Tear Down – C24-865-UA91

Acer Aspire C24 (D17WW3) Disassembly Guide

Introduction:

• Model: Acer Aspire C24 (D17WW3)
• Purpose: Upgrade SSD, DDR4 RAM, replace fan or motherboard.

Equipment Required:

• Phillips screwdriver
• Plastic prying tool

Disassembly Process:

Removing the Stand:

1. Place Computer on Screen: Lay the computer flat on its screen.
2. Remove Rubber Covers: Pry open two rubber covers on the stand to reveal screws.
3. Unscrew Stand: Remove four screws and then the stand.

Accessing Internals:

1. Remove Central Screw: There’s a small screw in the middle holding a bracket.
2. Remove Bracket: Pry open the plastic bracket covering the internals.
3. Unclip Wires: Ensure wires (like those from the speaker) are not tangled in the bracket.

Internal Components:

1. Hard Drive:
   • Located in the lower part.
   • Suitable for upgrading to an SSD.
   • Reinstall Windows 10 from a USB or disc after upgrading.
2. Motherboard Bracket:
   • Remove seven screws (three on each side and one in the middle).
   • Carefully lift the bracket to expose the motherboard and RAM.
3. RAM Upgrade:
   • The system uses DDR4 RAM.
   • Can be upgraded to a maximum of 16GB (2x 8GB modules).
4. Motherboard Replacement:
   • Disconnect all attached cables.
   • Unscrew the motherboard (five screws) for replacement.
5. Fan Replacement:
   • Located near the top of the motherboard.
   • Held by two screws and attached to the heatsink.
   • Replace if it makes unusual noise or fails to spin.

Reassembly Tips:

• Reverse the disassembly steps.
• Ensure all cables are correctly reconnected.
• Be gentle when handling internal components.

Conclusion:

• This guide helps you access and replace key components of the Acer Aspire C24 (D17WW3).
• Remember to handle components with care and ensure compatibility when upgrading.

Additional Tips:

• Always back up your data before performing hardware upgrades.
• Consider using an anti-static wristband when working with electronic components.
