Dell XPS P82G Teardown Tutorial

Hello, Simon here. In this video, I’ll guide you through a teardown of the Dell XPS, model P82G, ideal for those dealing with liquid spills on the keyboard or other issues requiring internal access.

Preparing for Teardown

• Laptop Model: Dell XPS, model P82G.
• Tools Needed: T5 Torx screwdriver (Link in the description for an electric screwdriver).
• Issue: Wine spill on the keyboard, examining potential internal damage.

Removing the Back Panel

• Unscrew: Remove all T5 Torx screws from the back panel.
• Opening: Pry open the back panel carefully after all screws are out.

Exploring Internal Components

1. Battery: Model DXGH8. Disconnect and unscrew for replacement if necessary (battery swollen, not charging, or affecting touchpad clickability).
2. M.2 SSD Drive: Original drive is 512GB. Can use a USB adapter for NVMe for data recovery or drive cloning.
3. CPU Fan and Heatsink: Check for dust or reapply thermal paste if overheating.
4. Disconnecting Cables: Disconnect speaker, CMOS battery, motherboard, touchpad, and Wi-Fi cables.
5. Motherboard Removal: Unscrew and gently lift the motherboard. Check for corrosion or damage, especially due to liquid spills.
6. LCD Screen: Recommend replacing the entire screen assembly, especially for touchscreen models, rather than just the glass for ease of repair and calibration.
7. Keyboard Replacement: Appears replaceable but recommend replacing the whole top assembly for convenience.

Conclusion

• Reassembly: Reverse the steps for putting the laptop back together.
• Final Thoughts: If this video helped with your repair or upgrade, please like and subscribe. Share your experiences or questions in the comments.

That’s it for the teardown of the Dell XPS model P82G. Thanks for watching, and remember to take care until next time!
