Lenovo Yoga 710 – 15IKB LCD Touch Screen Replacement

Lenovo Yoga 710 Screen Replacement Guide

Introduction:

• Model: Lenovo Yoga 710
• Purpose: Screen replacement, including touchscreen models.

Equipment Required:

• Phillips screwdriver
• Plastic prying tool
• Tweezers (optional)
• New replacement screen
• Double-sided adhesive tape for reassembly

Disassembly Process:

Opening the Laptop:

1. Open Screen: Fully open the laptop screen.
2. Remove Rubber Covers: At the bottom right corner, remove two small rubber covers to expose screws.

Removing the Screen:

1. Unscrew: Use a Phillips screwdriver to remove the two screws under the rubber covers.
2. Fold Laptop: Fold the laptop into a tablet (360 degrees) for easier handling.
3. Remove Plastic Covers: Pry off the plastic covers at the bottom of the screen.
4. Uncover More Screws: Look for any additional screws that might be hidden and remove them.
5. Detach Adhesive Tape: Carefully remove the adhesive tape holding the screen. This may require patience and delicacy to avoid breaking the tape.
6. Disconnect Cables: Gently disconnect the cables attached to the screen.
7. Remove the LCD Screen: Once the adhesive is fully detached, and cables are disconnected, the screen should come out easily.

Replacing the Screen:

1. Prepare New Screen: Align the new screen for installation.
2. Connect Cables: Reattach any cables from the old screen to the new one.
3. Apply Adhesive Tape: Use double-sided adhesive tape on the sides where the original adhesive was located.
4. Place the New Screen: Carefully align and place the new screen onto the laptop.
5. Apply Pressure: Gently press around the edges to ensure the adhesive grips properly.

Reassembly Tips:

• Reverse the disassembly steps.
• Ensure all screws are tightened properly.
• Be gentle when pressing the screen into place to avoid damage.

Conclusion:

• Replacing the screen on a Lenovo Yoga 710 requires careful handling due to the adhesive tape.
• Ensure the replacement screen matches the original specifications.

Additional Tips:

• Test the new screen before fully reassembling to ensure it’s working correctly.
• Consider practicing the removal of the adhesive on a less critical part if possible.
